Coordinate Measuring Machine Contact Angle Meter
| Minimum | 1 SET |
|---|---|
| Delivery | 15 days after order. |
| Model | HD-U805-1500 |
| Country | China |
| BrandName | HD |
| Package | Each set protected with resin fiber and PP film, then put into Strong wooden case with operation manual and video inside. |
| Payment | L/C, D/P, T/T |
| Price | FOB, CIF |
- Categories
Product Detail
Contact angle meter
Contact angle measurement was used for measuring the contact angle of a liquid on a solid, which wettability of liquid on the solid.
Contact angle goniometer can measure the contact angle of various liquids of various materials.
Contact angle meter for petroleum, printing and dyeing, pharmaceutical, paint, mineral processing industries such as scientific research and production has a very important role.
Parameter:
| Resolution | 0.01° |
| contact angle test range | 0-180° |
| camera System | CCD camera and Continuous zoom lens microscope, 25fps(55piexl/mm~315piexl/mm) |
| Light source | Monochrome LED cold light |
| Size | 560*200*360mm |
| Analysis | θ/ 2 , automatic |
| Accuracy | 0.1° |
| Rotating platform to test the forward / reverse angle, angle limit. | |
| Component: Auto rotating platform, video capture card, CCD camera, advanced zoom, automatic electric temperature control system, automatic precision injection, automatic image analysis systems, all-electric three-dimensional platform | |
Features:
a, Imaging: High pixel digital camera and Zooming lens, connection USB 2.0, 3 Million pixel, can clearly analysis dynamic liquid drop, and suitable to use laptop to operate.
b, Light source: brightness adjustable luminescence LED light, clear display liquid drop edge;
c, Specification: 25 frame/s, Microscope rate 0.7 – 4.5 continuous magnifying, zoom in 20- 200 times, imaging resolution 2048*1536;
d, Look down vision angle adjust range: 0–10° (useful for small angle or thin material imaging clearance).
e, Left and right angle adjust range: 0–10°
