Product Center

Thermal Cycle Chamber

Model

HD-E708

Country

China

BrandName

HD

Temperature range

-70℃~+180℃

Application

Rapid-Rate Thermal Cycle Chamber is ideally suited for specimen test requiring quick changes of temperature

Description

Rapid-rate Thermal Cycle Test Chamber is ideally suited for specimen test requiring quick changes of temperature. It can evaluate the failure of thermal mechanical properties of product. Normally the temperature rate is less than 20C/min, which can achieve the real application environment of testing sample by the fast ramp rate.

Specifications

Model HD-E708-100 HD-E708-150 HD-E708-225
Internal dimension 350*350*400mm 500*450*450mm 650*670*450mm
External dimension 1230*1270*1830mm 1380*1370*1980mm 1530*1590*1980mm
Externaldimension(Painttype 600*1080*1380mm 700*1080*1480mm 700*1180*1630mm
Temperature(℃) -20/-40/-70 -20/-40/-70 -20/-40/-70
Maximum Current(A) 22,22,28 22,22,28 18,18,23
Voltage(V) Single-phase220V Single-phase220V Three-phase380V
Temp,range 0℃;-20℃;-40℃;-70℃~+150℃
Test Method Pneumatic Operated Door Switch(two/three-zone)
Temp.Display Accuracy 0.01℃
Temp.uniformity ≤±2.0℃
Temp.deviation ±0.5℃~±0.2℃(without load)
Heating speed 1℃/min~20℃/min,can be customized
Cooling Speed 1℃/min~20℃/min,can be customized
Humid.range 20%~98%RH
Humid.resolution 0.1% R.H.
Humid.uniformity ±3%RH(without load)
Internal chamber material Stainless steel 304
External chamber material Stainless steel/paint spray



Structure

HD-E708-Thermal-Cycle-Chamber-3

Features

1. Has cable ports are provided on the left side to allow easy wiring of specimens for measurement or voltage application;
2. The door equipped with hinges preventing auto-closing;
3. Can designed to comply with major environmental test standards like IEC, JEDEC, SAE…
4. This chamber is safety tested with CE certificate.

PLC Controller

The controller adopts LCD touch screen,and it is with automatic,intelligent and humanized design.
2022101809281
20221018092908

Material of lnner Chamber

SUS304 mirror stainless steel plate,cor-rosion-resistant,easy to clean,beautiful and generous.
